1

   額定二次輸出（測量級）
Secondary rated output (measurement)

1V、1.5V、2.5V、4V

2

    額定二次輸出（保護級）
Secondary rated output (protect)

150mV、200mV(空心線圈)
Air core coil

3

 額定二次輸出（保護級）
Secondary rated output (protect)

225mV、500mV(小鐵心線圈)
Smail  core  type  coil

4

        額定輸出數字量（測量級）
Rated output digital quantity (measurement)

0×2D41

5

   額定輸出數字量(保護級)
Rated digital output for protection

0×01CF/0×00E7

6

 測量級準確級
Accurately class for measured

0.2S、0.2

7

   保護級準確級
Accurately class for protection

5TPE(空心線圈)
Air core coil

8

 保護級準確級
Accurately class for protection

5P25(小鐵芯線圈)
Smail  core  type  coil

9

 額定負荷
rated burden

2KΩ、20KΩ、2MΩ

10

暫定特性的額定對稱短路電流倍數
Rated symmetrical short -circuit -current
Facior for iransient performance

25

11

額定喚醒時間
Ratedd wake up time

100mS

12

額定一次時間常數
Rated a time constant

0

 額定一次電流
rated primary
current(A)

額定短時熱電流
 rated short time thermal current（Ith）


  額定動穩定電流
  rated dynamic current
 （Idyn）

30-150

150Ith

375Ith

200

24.5

45

300-400

31.5

80

500-600

45

112.5

800-1250

63

130
